3-48
Chapter 3: BIOS setup
Chapter 3
Intel LAN Controller [Enabled]
This item allows you to enable or disable the Intel LAN1/2 controllers.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set the Intel LAN Controller to [Enabled].
Intel Lan PXE Option ROM [Disabled]
This item allows you to enable or disable the PXE Option Rom of the Intel
®
LAN
controller.
Conguration options: [Enabled] [Disabled]
Realtek LAN Controller [Enabled]
This item allows you to enable or disable the Intel LAN1/2 controllers.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set the Intel LAN Controller to [Enabled].
Intel PXE Option ROM [Disabled]
This item allows you to enable or disable the PXE OptionRom of the Intel
®
LAN
controller.
Conguration options: [Enabled] [Disabled]
Serial Port Configuration
This item allows you to set parameters of Serial Port.
This item function only if there is a serial port (COM1) connector on a motherboard.
Serial Port [On] [Off]
This item allows you to enable or disable serial port.
Change Settings
This item allows you to select an optimal setting for Super IO device.
