xii
Back Panel I/O Ports
1 x Optical S/PDIF Output
1 x USB BIOS Flashback button
2 x LAN (RJ45) port
2 x USB 3.1/3.0 ports (teal blue, supports ASUS USB 3.1 Boost)
4 x USB 3.0/2.0 ports (blue, 1 supports USB BIOS Flashback)
4 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Internal I/O connectors
2 x USB 3.0/2.0 connector support additional 4 USB 3.0/2.0 ports
(19-bin; beige)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
8 x SATA 6 Gb/s connectors (2 x beige; 2 x gray at beneath of
SATA Express connector; 4 x black)
1 x CPU Fan connector (4-pin white) for both 4-pin (PWM mode)
and 3-pin (DC mode) CPU coolers control with auto detection
support
1 x CPU OPT Fan connector (4-pin black) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control
4 x Chassis Fan connectors (4-pin Black) for both 4-pin (PWM
mode) and 3-pin (DC mode) CPU coolers control
5 x Assistant Fan connectors (4 x 4-pin [beige]; 1 x 4-pin for dust
de-fan [white])
Front panel audio connector (AAFP)
24-pin EATX Power connector
8 + 4-pin EATX Power connector
System panel (Q-Connector)
1 x MemOK! button
1 x DRCT (DirectKey) connector
3 x Thermal Sensor (T_Sensor) headers
1 x chassis intrusion header
1 x S/PDIF Out header
1 x TPM header
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX series
support
1 x Clear CMOS jumper
SABERTOOTH X99
specifications summary
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0,
SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2,
CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My
Favorites, Quick Note, Last Modied Log, F12 PrintScreen function,
F3 Shortcut functions, and ASUS DRAM SPD (Serial Presence
Detect) memory information
Manageability
WfM 2.0, DMI 2.7, WOL by PME, PXE
Support DVD contents
Drivers
Anti-virus software (OEM version)
ASUS/TUF CPU-Z
ASUS Utilities
Form factor
ATX form factor: 12.0 in. x 9.6 in. (30.5 cm x 24.4 cm)
