Asus tuf sabertooth x99 [15/186] Installation tools and components

Installation tools and components

Graphics card (optional) Philips (cross) screwdriver

PC chassis Power supply unit

Intel

LGA2011-v3 CPU Intel

LGA2011-v3 compatible CPU Fan

DIMM SATA hard disk drive

SATA optical disc drive (optional)

The tools and components in the table above are not included in the motherboard package.
