1-10
Chapter 1: Product introduction
DDR4 3200 (O.C.) MHz capability
DDR4 3000 (O.C.) MHz capability
DDR4 2800 (O.C.) MHz capability
Vendors Part No. Size SS/DS Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
G.SKILL F4-3200C16Q-16GRR 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3200C16Q-16GRB 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3200C16Q-16GRRK 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V • •
AVEXIR AVD4U32001604G-4BZ1 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-18-18-36 1.35V •
AVEXIR AVD4U32001604G-4CIR 16GB(4GB*4) SS - - 16-18-18-36 1.35V •
CORSAIR CMD16GX4M4A3200C16 16GB(4GB*4) SS - - 16-18-18-36 1.35V •
GEIL GPR416GB3200C15QC 16GB(4GB*4) SS - - 15-15-15-35 1.35V •
Kingston HX432C16PB2K4/16 16GB(4GB*4) SS - - 16-16-16-39 1.35V •
panram PUD43200C164G4NJW 16GB(4GB*4) SS - - 16-18-18-39 1.35V •
Vendors Part No. Size SS/DS Chip Brand Chip NO. Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
G.SKILL F4-3000C15Q-32GRR 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V •
G.SKILL F4-3000C15Q-32GRB 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V •
G.SKILL F4-3000C15Q-32GRK 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V •
G.SKILL F4-3000C16Q-32GRR 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V •
G.SKILL F4-3000C16Q-32GRB 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V •
G.SKILL F4-3000C16Q-32GRK 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V •
G.SKILL F4-3000C15Q-16GRR 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q-16GRB 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q-16GRK 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q2-32GRK 32GB(4GB*8) SS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V • •
G.SKILL F4-3000C15D-8GTZ 8GB(4GB*2) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
AVEXIR AVD4U30001604G-4CI 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-18-18-36 1.35V • •
AVEXIR AVD4U30001504G-4BZ1 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 15-15-15-35 1.35V • •
AVEXIR AVD4U30001608G-4CI 32GB(8GB*4) DS SKhynix H5AN4G8NMFR 16-18-18-36 1.35V •
Kingston HX430C15PB2K4/16 16GB(4GB*4) SS - - 15-16-16-39 1.35V • •
CORSAIR CMD16GX4M4B3000C15 16GB(4GB*4) SS Samsung K4A4G085WD 15-17-17-35 1.35V • •
CORSAIR CMK16GX4M4B3000C15 16GB(4GB*4) SS Samsung K4A4G085WD 15-17-17-35 1.35V • •
Panram PUD43000C154G4NJW 16GB(4GB*4) SS - - 15-17-17-35 1.35V • •
Asint SLB404G08-EWWHMX 16GB(8GB*2) SS SKhynix H5AN4G8NMFR 15-15-15-44 1.35V •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
ADATA AX4U2800W4G17 32GB(8x4GB) DS - - 17-17-17-36 1.2 • • •
ADATA AX4U2800W8G17 8GB DS - - 15-15-15-36 1.2 • • •
Apacer 78.BAGM8.AF20B(XMP) 4GB SS - - 17-17-17-36 - • • •
Apacer 78.CAGM8.AF30B(XMP) 8GB DS - - 17-17-17-36 - • • •
AVEXIR AVD4U28001504G-4CIR(XMP) 4GB SS - - 15-15-15-35 1.35 • • •
AVEXIR AVD4U28001608G-4CIR(XMP) 32GB(8x4GB) DS - - 16-16-16-36 1.2 • •
CORSAIR CMD16GX4M4A2800C16(Ver4.23)(XMP) 16GB(4x4GB) SS - - 16-18-18-36 1.2 • • •
CORSAIR CMD16GX4M4A2800C16(Ver5.29) 16GB(4x4GB) SS - - 16-18-18-36 1.2 • • •
CORSAIR CMD32GX4M4A2800C16(Ver5.29)(XMP) 32GB(4x8GB) DS - - 18-18-18-36 1.2 • • •
CORSAIR CMK16GX4M4A2800C16(Ver4.23)(XMP) 16GB(4x4GB) SS - - 16-16-18-36 1.2 • • •
CORSAIR CMK16GX4M4A2800C16(Ver5.29) 16GB(4x4GB) SS - - 16-18-18-36 1.2 • • •
CORSAIR CMK32GX4M4A2800C16(Ver5.29)(XMP) 32GB(4x8GB) DS - - 16-18-18-36 1.2 • • •
G.SKILL F4-2800C15Q2-64GRK(XMP) 64GB(8x8GB) DS - - 15-16-16-35 1.25 • • •
G.SKILL F4-2800C16Q-16GRR(XMP) 16GB(4x4GB) SS - - 16-16-16-36 1.2 • • •
G.SKILL F4-2800C16Q-32GRR(XMP) 32GB(4x8GB) DS - - 16-16-16-36 1.2 • • •
Kingston HX428C14PBK4/16(XMP) 16GB(4x4GB) SS - - 14-15-15-40 1.35 • • •
Panram PUD42800C164G4NJW(XMP) 16GB(4x4GB) SS - - 16-18-18-36 1.25 • • •
DDR4 3300 (O.C.) MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
G.SKILL F4-3300C16Q-16GRK 16GB(4GB*4) SS SKhynix H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3300C16D-8GTZ 8GB(4GB*2) SS Samsung K4A4G085WD 16-18-18-38 1.35V • •
CORSAIR CMD16GX4M4B3300C16 16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-36 1.35V •
