Asus z170 pro gaming [22/100] Ddr4 2133 mhz capability
![Asus z170 pro gaming [22/100] Ddr4 2133 mhz capability](/views2/1162361/page22/bg16.png)
1-12
Chapter 1: Product introduction
DDR4 2133 MHz capability
• SS:Single-sided/DS: Double-sided
DIMM support:
• 1 DIMM:Supportsone(1)moduleinsertedintoanyslotasSingle-channelmemory
conguration.InstallthemoduleintoA2slotforbettercompatibility.
• 2 DIMMs:Supportstwo(2)modulesinsertedintothesamecolorslotsasonepairof
Dual-channelmemoryconguration.InstallthemodulesintoA2/B2slots
for better compatibility.
• 4DIMMs:Supportsfour(4)modulesinsertedintobothA1/A2andB1/B2slotsastwo
pairsofDual-channelmemoryconguration
• VisittheASUSwebsiteatwww.asus.comforthelatestQVL.
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
ADATA AD4U2133W4G15-B 4GB SS SKHynix H5AN4G8NMFRTFC 15-15-15-36 - • • •
ADATA AD4U2133W8G15 8GB DS SKHynix H5AN4G8NMFRTFC 15-15-15-36 1.2 • • •
Apacer 78.B1GM3.AF00B 4GB SS SKHynix H5AN4G8NMFRTFC 15-15-15-36 1.2 • • •
Apacer 78.C1GM3.AF10B 8GB DS SKHynix H5AN4G8NMFRTFC 15-15-15-36 1.2 • • •
AVEXIR AVD4U21331504G-4M 4GB SS AVEXIR 512X8DDR4 15-15-15-35 1.2 • • •
Century CD8G-D4U2133 8GB DS SKHynix H5AN4G8NMFRTFC 15-15-15-36 - • • •
CORSAIR
CMK16GX4M4A2133C13
(Ver4.23)(XMP)
16GB(4x4GB) SS - - 13-15-15-28 1.2 • • •
CORSAIR
CMK32GX4M4A2133C13
(Ver4.23)(XMP)
32GB(4x8GB) DS - - 13-15-15-28 1.2 • • •
CORSAIR
CMK64GX4M8A2133C13
(Ver4.23)(XMP)
64GB(8x8GB) DS - - 13-15-15-28 1.2 • • •
CORSAIR CMV4GX4M1A2133C15 4GB SS - - 15-15-15-36 1.2 • • •
CORSAIR CMV8GX4M1A2133C15 8GB DS - - 15-15-15-36 1.2 • • •
G.SKILL F4-2133C15Q-16GRR 16GB(4x4GB) SS - - 15-15-15-35 1.2 • • •
G.SKILL F4-2133C15Q-32GRR 32GB(4x8GB) DS - - 15-15-15-35 - • • •
ISDT IMA41GU6MFR8N-TF0 8GB DS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • • •
ISDT IMA451U6MFR8N-TF0 4GB SS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • • •
Panram PUD42133C134G4NJW 16GB(4x4GB) SS - - 13-13-13-35 1.2 • • •
Panram PUD42133C138G4NJW 32GB(4x8GB) DS - - 13-13-13-35 1.2 • • •
Panram PUD42133C154G2VS 8GB(2x4GB) SS SKHynix H5AN4GBNMFRTFC 15-15-15-36 1.2 • • •
Panram PUD42133C154GNJK 4GB SS - - 15-15-15-36 1.2 • • •
Panram PUD42133C158G2VS 16GB(2x8GB) DS SKHynix H5AN4GBNMFRTFC 15-15-15-36 1.2 • • •
Panram PUD42133C158GNJK 8GB DS - - 15-15-15-36 1.2 • • •
Samsung M378A1G43DB0-CPB 8GB DS Samsung K4A4G085WD 15-15-15-36 - • • •
SanMax SMD-4G28HP-21P 4GB SS SKHynix H5AN4G8NMFRTFC 15-15-15-37 - • • •
SanMax SMD-8G28HP-21P 8GB DS SKHynix H5AN4G8NMFRTFC 15-15-15-37 - • • •
SKHynix HMA82GU6MFR8N-TF 16GB DS SKHynix H5AN8G8NMFRTFC 15-15-15-36 - • • •
SUPER
TALENT
FBU2B008GM 8GB DS Micron D9RGQ 15-15-15-36 1.2 • • •
Team TED44GM2133C15ABK 4GB SS SKHynix H5AN4G8NMFRTFC 15-15-15-36 1.2 • • •
Transcend TS1GLH64V1H 8GB DS Samsung K4A4G085WD 15-15-15-37 - • • •
Transcend TS512MLH64V1H 4GB SS Samsung K4A4G085WD 15-15-15-37 - • • •
UMAX
84G44G93MC-
21OMCALGF15
4GB SS Micron D9RGQ 15-15-15-36 - • • •
UMAX
84G48G93MC-
21OMCGNGF15
8GB DS Micron D9RGQ 15-15-15-36 - • • •
