Z170 PRO GAMING specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS Gaming Motherboard – Z170 PRO GAMING
Cables
4 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x ROG SLI bridge connector
1 x PRO GAMING cable labels
1 x M.2 screw package
1 x CPU installation tool
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
Z170 Express Chipset
Memory
4 x DIMM, maximum 64 GB, DDR4 3400(O.C.)*/3333(O.C.)*/3200(O.C.)*/
3100(O.C.)*/3000(O.C.)*/2933(O.C.)*/2800(O.C.)*/2666(O.C.)*/2600(O.C.)*/
2400(O.C.)*/2133 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualied Vendors List) for details.
** Refer to www.asus.com or this user manual for the Memory QVL (Qualied Vendors
List).
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort, HDMI, D-sub, DVI ports
- Supports DisplayPort 1.2 with maximum resolution of 4096 x 2304@60Hz
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160@24Hz
- Supports DVI with maximum resolution of 1920 x 1200 @ 60 Hz
- Supports D-sub with maximum resolution of 1920 x 1200 @ 60 Hz
- Supports up to three displays simultaneously
Supports Intel
®
InTru
TM
3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider
TM
Maximum shared memory of 512 MB
Expansion
slots
2 x PCI Express 3.0 x16 slots (single at x16 mode or dual at X8 mode)
1 x PCI Express 3.0 x16 slot (max. at x4 mode)
3 x PCI Express 3.0 x1 slots
