ASUS Z170 PRO GAMING
1-11
DDR4 2666 (O.C.) MHz capability
DDR4 2400 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
AVEXIR AVD4U26661504G-4CIR(XMP) 4GB SS - - 15-15-15-35 1.2 • • •
AVEXIR AVD4U26661608G-4CIR(XMP) 32GB(8x4GB) DS - - 16-16-16-36 1.2 • • •
CORSAIR
CMD128GX4M8A2666C15(Ver4.31)
(XMP)
128GB(16x
8GB)
DS - - 15-17-17-35 1.2 • • •
CORSAIR
CMD16GX4M4A2666C15(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 15-17-17-35 1.2 • • •
CORSAIR
CMD16GX4M4A2666C16(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 16-18-18-35 1.2 • • •
CORSAIR
CMD16GX4M4A2666C16(Ver5.29)
(XMP)
16GB(4x4GB) SS - - 16-18-18-35 1.2 • • •
CORSAIR
CMD32GX4M4A2666C15(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 15-17-17-35 1.2 • • •
CORSAIR CMD32GX4M4A2666C15(Ver5.29) 32GB(4x8GB) DS - - 15-17-17-35 1.2 • • •
CORSAIR
CMD32GX4M4A2666C16(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 16-18-18-35 1.2 • • •
CORSAIR
CMK16GX4M4A2666C15(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 15-17-17-35 1.2 • • •
CORSAIR CMK16GX4M4A2666C15(Ver5.29) 16GB(4x4GB) SS - - 15-17-17-35 1.2 • • •
CORSAIR
CMK16GX4M4A2666C16(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 16-18-18-35 1.2 • • •
CORSAIR
CMK16GX4M4A2666C16(Ver5.29)
(XMP)
16GB(4x4GB) SS - - 16-18-18-35 1.2 • • •
CORSAIR
CMK32GX4M4A2666C15(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 15-17-17-35 1.2 • • •
CORSAIR
CMK32GX4M4A2666C15(Ver5.29)
(XMP)
32GB(4x8GB) DS - - 15-17-17-35 1.2 • • •
CORSAIR
CMK32GX4M4A2666C16(Ver5.29)
(XMP)
32GB(4x8GB) DS - - 16-16-18-35 1.2 • • •
CORSAIR
CMK32GX4M4A2666C16R(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 16-18-18-35 1.2 • • •
G.SKILL F4-2666C15Q-16GRR(XMP) 16GB(4x4GB) SS - - 15-15-15-35 1.2 • • •
G.SKILL F4-2666C15Q-32GRR(XMP) 32GB(4x8GB) DS - - 15-15-15-35 1.2 • • •
G.SKILL F4-2666C16Q2-64GRB(XMP) 64GB(8x8GB) DS - - 16-16-16-36 1.2 • • •
ISDT IMA41GU6MFR8N-CF0(XMP) 8GB DS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • • •
ISDT IMA451U6MFR8N-CF0(XMP) 4GB SS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • • •
Team TCD44G2666C15ABK(XMP) 4GB SS Samsung K4A4G085WD 15-15-15-35 1.2 • • •
Team TCD48G2666C15ABK(XMP) 32GB(4x8GB) DS Team
TCD48G2666C
15ABK
15-15-15-35 1.2 • • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
AVEXIR AVD4U24001604G-4CIR(XMP) 4GB SS - - 16-16-16-36 1.2 • • •
AVEXIR AVD4U24001608G-4M 32GB(8x4GB) DS SKHynix
H5AN4G8NM
FRTFC
16-16-16-39 1.2 • • •
AVEXIR AVD4U24001608G-4M(XMP) 32GB(8x4GB) DS SKHynix
H5AN4G8NM
FRTFC
16-16-16-36 1.2 • • •
CORSAIR
CMD16GX4M4A2400C14(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 14-16-16-31 1.2 • • •
CORSAIR
CMD32GX4M4A2400C14(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 14-16-16-31 1.2 • • •
CORSAIR
CMK16GX4M4A2400C14(Ver4.23)
(XMP)
16GB(4x4GB) SS - - 14-16-16-31 1.2 • • •
CORSAIR
CMK32GX4M4A2400C14(Ver4.23)
(XMP)
32GB(4x8GB) DS - - 14-16-16-31 1.2 • • •
Crucial BLS4G4D240FSA.8FAD 4GB SS - - 16-16-16-40 1.2 • • •
crucial BLS4G4D240FSA.8FAR(XMP) 4GB SS - - 17-16-16-39 1.2 • • •
Crucial BLS8G4D240FSA.16FAD 8GB DS - - 16-16-16-40 1.2 • • •
crucial BLS8G4D240FSA.16FAR(XMP) 8GB DS - - 17-16-16-39 1.2 • • •
G.SKILL F4-2400C15Q-16GRR 16GB(4x4GB) SS - - 15-15-15-35 1.2 • • •
G.SKILL F4-2400C15Q2-128GRK(XMP)
128GB(8x
16GB)
DS - - 15-15-15-35 1.2 • • •
G.SKILL F4-2400C15Q-32GRR 32GB(4x8GB) DS - - 15-15-15-35 1.2 • • •
Kingston HX424C12PB2K4/16 16GB(4x4GB) SS - - 15-15-15-36 1.2 • • •
Panram PUD42400C154G4NJW 16GB(4x4GB) SS - - 15-15-15-35 1.2 • • •
Panram PUD42400C158G4NJW 32GB(4x8GB) DS - - 15-15-15-35 1.2 • • •
Team TED44GM2400C16BK 4GB SS Samsung K4A4G085WD 16-16-16-39 1.2 • • •
Team TED48GM2400C16BK 8GB DS Samsung K4A4G085WD 16-16-16-39 1.2 • • •
V-color TD4G8C17-UH 4GB SS V-color DW3J0460HM 15-15-15-36 1.2 • • •
