xii
Internal I/O
Connectors
1 x S/PDIF out header
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX series support
1 x TPM connector
1 x COM port
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System Panel
1 x Speaker header
1 x MemOK! button
1 x Clear CMOS jumper
1 x DRCT (Direct Key) connector
1 x 5-pin EXT_FAN (Extension Fan) connector
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modied
log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Accessories
2 x Serial ATA 6.0Gb/s cables
1 x ASUS SLI bridge connector
1 x M.2 screw package
1 x User’s manual
1 x CPU installation tool
Support DVD
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Operating
System
Support
Windows
®
10*
Windows
®
8.1*
Windows
®
7
*64-bit supported only
Form Factor ATX Form Factor, 12”x 9.2” (30.5cm x 23.4cm)
Z170-E specifications summary
Specications are subject to change without notice.
