vii
Z170-E specifications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items:
Motherboard
ASUS Z170-E Motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x ASUS SLI bridge connector
1 x M.2 screw package
1 x CPU installation tool
Application DVD
Support DVD
Documentation
User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7/ i5/ i3/Pentium
®
/Celeron
®
Processors
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
Chipset
Intel
®
Z170 Express Chipset
Memory
4 x DIMM, max. 64GB, DDR4 3466(O.C.*)/3400(O.C.)*/3333(O.C.)*/3300(O.C.)*/
3200(O.C.)*/3000(O.C.)*/2800(O.C.)*/2666(O.C.)*/2400(O.C.)*/2133 MHz, non-
ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to Memory QVL (Qualified Vendors List) for details.
Expansion
Slots
2 x PCI Express 3.0/2.0 x16 slots (single at x16 or dual at x8/x8 mode)
1 x PCI Express 3.0/2.0 x16 slot
(max. at x2 mode, compatible with PCIe x1 and x2 devices)
3 x PCI Express 3.0/2.0 x1 slots
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D ports
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz / 2560 x
1600@60Hz
Supports DVI-D with max. resolution 1920 x 1200@60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™
Supports up to 2 displays simultaneously
Maximum shared memory of 512MB
