1-12
Chapter 1: Product Introduction
DDR4 3000 (O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1 2 4
G.SKILL F4-3000C15Q-16GRR 16GB(4GB*4) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q-16GRB 16GB(4GB*4) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q-16GRK 16GB(4GB*4) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
G.SKILL F4-3000C15Q2-32GRK 32GB(4GB*8) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
G.SKILL F4-3000C15D-8GTZ 8GB(4GB*2) SS Samsung K4A4G085WD 15-15-15-35 1.35V • •
AVEXIR AVD4U30001604G-4CI 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 16-18-18-36 1.35V • •
AVEXIR AVD4U30001504G-4BZ1 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 15-15-15-35 1.35V • •
Kingston HX430C15PB2K4/16 16GB(4GB*4) SS 15-16-16-39 1.35V • •
CORSAIR CMD16GX4M4B3000C15 16GB(4GB*4) SS Samsung K4A4G085WD 15-17-17-35 1.35V • •
CORSAIR CMK16GX4M4B3000C15 16GB(4GB*4) SS Samsung K4A4G085WD 15-17-17-35 1.35V • •
Panram PUD43000C154G4NJW 16GB(4GB*4) SS 15-17-17-35 1.35V • •
(continued on the next page)
DDR4 2800 (O.C.) MHz capability
Vendors
Part No.
Size SS/DS
Chip
Brand
Chip
NO.
Timing
Voltage DIMM socket
support (Optional)
1 2 4
ADATA AX4U2800W4G17 32GB
(4GB*8)
DS - - 17-17-17-36 1.2 • • •
ADATA AX4U2800W8G17 8GB DS - - 15-15-15-36 1.2 • • •
Apacer 78.BAGM8.AF20B(XMP) 4GB SS - - 17-17-17-36 - • • •
Apacer 78.CAGM8.AF30B(XMP) 8GB DS - - 17-17-17-36 - • • •
AVEXIR AVD4U28001504G-4CIR(XMP) 4GB SS - - 15-15-15-35 1.35 • • •
AVEXIR AVD4U28001608G-4CIR(XMP) 32GB
(4GB*8)
DS - - 16-16-16-36 1.2 • •
CORSAIR CMD16GX4M4A2800C16(Ver4.23)
(XMP)
16GB
(4GB*4)
SS - - 16-18-18-36 1.2 • • •
CORSAIR CMD16GX4M4A2800C16(Ver5.29) 16GB
(4GB*4)
SS - - 16-18-18-36 1.2 • • •
CORSAIR CMD32GX4M4A2800C16(Ver5.29)
(XMP)
32GB
(8GB*4)
DS - - 18-18-18-36 1.2 • • •
CORSAIR CMK16GX4M4A2800C16(Ver4.23)
(XMP)
16GB
(4GB*4)
SS - - 16-16-18-36 1.2 • • •
CORSAIR CMK16GX4M4A2800C16(Ver5.29) 16GB
(4GB*4)
SS - - 16-18-18-36 1.2 • • •
CORSAIR CMK32GX4M4A2800C16(Ver5.29)
(XMP)
32GB
(8GB*4)
DS - - 16-18-18-36 1.2 • • •
G.SKILL F4-2800C15Q2-64GRK(XMP) 64GB
(8GB*8)
DS - - 15-16-16-35 1.25 • • •
G.SKILL F4-2800C16Q-16GRR(XMP) 16GB
(4GB*4)
SS - - 16-16-16-36 1.2 • • •
G.SKILL F4-2800C16Q-32GRR(XMP) 32GB
(8GB*4)
DS - - 16-16-16-36 1.2 • • •
Kingston HX428C14PBK4/16(XMP) 16GB
(4GB*4)
SS - - 14-15-15-40 1.35 • • •
Panram PUD42800C164G4NJW(XMP) 16GB
(4GB*4)
SS - - 16-18-18-36 1.25 • • •
