2-42

Chapter 2: BIOS Setup

HD Audio Controller [Enabled]

This item allows you to use the Azalia High Denition Audio Controller

Conguration options: [Disabled] [Enabled]

The following items appear only when you set the HD Audio Controller to [Enabled].

Front Panel Type [HD Audio]

This item allows you to set the front panel audio connector (AAFP) mode to legacy

AC’97 or high-denition audio depending on the audio standard that the front panel

audio module supports.

[HD Audio] Sets the front panel audio connector (AAFP) mode to high denition

audio.

[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97

SPDIF Out Type [SPDIF]

[SPDIF] Sets to an SPDIF audio output.

[HDMI] Sets to an HDMI audio output.

Audio LED Lighting [Breathing Mode]

[Disabled] Turn off the Audio LED.

[Still Mode] Turn on the Audio LED.

[Breathing Mode] Turn on Audio LED breathing mode.

The following items appear only when you set the Audio LED Lighting to [Still Mode] or

[Breathing Mode].

S3/S4/S5 Audio LED [Disabled]

This item allows you to enable or disable the audio LED in S3/S4/S5 mode.

Conguration Options: [Disabled] [Enabled]

M.2 and SATA Express Mode Configuration [SATA EXpress]

[M.2] SATA mode will be switched to M.2. SATA Express can only support PCIE

devices.

[SATA EXpress] SATA mode will be switched to SATA Express. M.2 can only support PCIE

devices.

ASMedia USB 3.1 Controller [Enabled]

This item allows you to disable or enable the ASMedia

USB 3.1 controller of your system.

Conguration options: [Disabled] [Enabled]

ASMedia USB 3.1 Battery Charging Support [Disabled]

This item allows you to disable or enable the ASMedia USB 3.1 battery charging support of

your system.

Conguration options: [Disabled] [Enabled]
