Asus P9X79 [65/156] Chapter 2

ASUS P9X79 2-47

Chapter 2

Connect to 4.1 channel Speakers

Connect to 5.1 channel Speakers

Connect to 7.1 channel Speakers

When the DTS UltraPC II function is enabled, ensure to connect the rear speaker to the

gray port.
