- 61 - Unique Features
D. Using the Restore Function in Xpress Recovery2
E. Removing the Backup
F. Exiting Xpress Recovery2
Select RESTORE to restore the backup to your hard drive in case
the system breaks down. The RESTORE option will not be present
if no backup is created before.
Select REBOOT to exit Xpress Recovery2.
Step 2:
After the backup le is removed, no backup image le
will be present in Disk Management and hard drive
space will be freed up.
Step 1:
If you wish to remove the backup file, select
REMOVE.
