Appendix
- 74 -
The pictures to the right show the 7.1-channel speak-
ercongurations.
7.1-Channel Speakers:
Center/Subwoofer
Speaker Out
Front Speaker Out
Rear Speaker Out
Side Speaker Out
B.ConguringSoundEffect
YoumaycongureanaudioenvironmentontheSound Effects tab.
Step 2:
Connect an audio device to an audio jack. The The cur-
rent connected device is dialog box appears. Select the
device according to the type of device you connect. Then
click OK.
Step 3:
On the Speakers screen, click the SpeakerCongura-
tion tab. In the SpeakerConguration list, select Stereo,
Quadraphonic, 5.1 Speaker, or 7.1 Speaker according to
thetypeofspeakercongurationyouwishtosetup.Then
the speaker setup is completed.
