Chapter 2 Hardware Description and Connection
GS1100 Series User’s Guide
13
The following table describes the LEDs.
2.3 Hardware Installation
See the following table for a comparison of the hardware installation methods of each GS1100
model:
Table 4 GS1100 Series Installation Comparison Table
Note: Ask an authorized technician to attach the Switch to the rack/wall.
For GS1100-8HP and GS1100-16, you can place the Switch directly on top of your desk or have it
wall-mounted. For GS1100-16 and GS110-24, the size is suitable for rack-mounting and you can
refer to Section 2.3.2 on page 14 for instruction. Take note of the following:
• The Switch should have a minimum 25 mm space around it for ventilation.
• The Switch should be placed in a desk that has a level surface and that is able to support the
weight of the Switch.
To start using it, simply connect the power cables and turn on the Switch.
Table 3 The Front Panel LED Descriptions
LED COLOR STATUS DESCRIPTION
PWR Green On The Switch is on and receiving power.
Off The Switch is not receiving power.
PoE MAX Red On Power supplied to the PoE port(s) reachs the power budget limit or
exceeds the total PoE power budget on the Switch.
Off Power supplied to the PoE port(s) is below the power budget limit.
PoE Amber On Power is supplied to the PoE port.
Off Power is not supplied to the PoE port.
LINK/
ACT
Green On The port is connected to an Ethernet network.
Blinking The port is receiving or transmitting data.
Off The port is not connected to an Ethernet network.
1G
10/100
Green On The port is connected to an Ethernet network at 1000M speed.
Blinking The port is receiving or transmitting data at 1000M speed.
Amber On The port is connected to an Ethernet network at 10M or 100M speed.
Blinking The port is receiving or transmitting data at 10M or 100M speed.
Off The port is not connected to an Ethernet network.
MODEL FEATURE GS1100-8HP GS1100-16 GS1100-24
Desktop Device
Wall-mountable
Rack-mountable
