Zyxel GS1100-8HP [9/22] Hardware description and connection
![Zyxel GS1100-8HP [9/22] Hardware description and connection](/views2/1168494/page9/bg9.png)
GS1100 Series User’s Guide 9
CHAPTER 2
Hardware Description and Connection
2.1 Rear Panel
The three-pronged power receptacle is located on the rear panel of the Switch. Refer to the power
supply requirements on the panel.
Figure 5 Rear Panel
2.1.1 Rear Panel Power Connection
Connect one end of the supplied power cord to the power receptacle on the back of the Switch and
the other end to the appropriate power source.
For the GS1100-8HP and GS1100-16, use the POWER ON/OFF switch to have the Switch power
on or off.
2.2 Front Panel
The front panel of the Switch includes the auto-negotiating 10 Base-T/100 Base-TX/1000 Base-T
RJ-45 ports and the LEDs.
The GS1100-24 has two mini-GBIC ports. Refer to Section 2.2.3 on page 10 for more information.
GS1100-16
GS1100-24
GS1100-8HP
