Chapter 16 LEDs
NWA5000 / WAC6000 Series User’s Guide
182
Figure 106 Maintenance > LEDs > Locator
The following table describes fields in the above screen.
Table 84 Maintenance > LED > Locator
LABEL DESCRIPTION
Turn On
Turn Off
Click Turn On button to activate the locator. The Locator function will show the
actual location of the WAC between several devices in the network.
Otherwise, click Turn Off to disable the locator feature.
Automatically Extinguish
After
Enter a time interval between 1 and 60 minutes to stop the locator LED from
blinking. Default is 10 minutes.
Apply Click Apply to save changes in this screen.
Refresh Click Refresh to update the information in this screen.
