Chapter 3 Dashboard
NWA5000 / WAC6000 Series User’s Guide
43
System Resources
CPU Usage This field displays what percentage of the NWA/WAC’s processing capability is currently
being used. Hover your cursor over this field to display the Show CPU Usage icon that
takes you to a chart of the NWA/WAC’s recent CPU usage.
Memory Usage This field displays what percentage of the NWA/WAC’s RAM is currently being used.
Hover your cursor over this field to display the Show Memory Usage icon that takes
you to a chart of the NWA/WAC’s recent memory usage.
Flash Usage This field displays what percentage of the NWA/WAC’s onboard flash memory is
currently being used.
Ethernet Neighbor
Local Port
(Description)
This field displays the port of the NWA/WAC, on which the neighboring device is
discovered.
Model Name This field displays the model name of the discovered device.
System Name This field displays the system name of the discovered device.
FW Version This field displays the firmware version of the discovered device.
Port
(Description)
This field displays the discovered device’s port which is connected to the NWA/WAC.
IP This field displays the IP address of the discovered device. Click the IP address to
access and manage the discovered device using its web configurator.
MAC This field displays the MAC address of the discovered device.
WDS (Wireless Distribution System) Uplink/Downlink Status
MAC Address This field displays the MAC address of the root AP or repeater to which the NWA/WAC is
connected using WDS.
Radio This field displays the radio number on the root AP or repeater to which the NWA/WAC
is connected using WDS.
Channel This field displays the channel number on the root AP or repeater to which the NWA/
WAC is connected using WDS.
SSID This field displays the name of the wireless network to which the NWA/WAC is
connected using WDS.
Security Mode This field displays which secure encryption methods is being used by the NWA/WAC to
connect to the root AP or repeater using WDS.
Link Status This field displays the RSSI (Received Signal Strength Indicator) and transmission/
reception rate of the wireless connection in WDS.
System Status
System Uptime This field displays how long the NWA/WAC has been running since it last restarted or
was turned on.
Current Date/
Time
This field displays the current date and time in the NWA/WAC. The format is yyyy-mm-
dd hh:mm:ss.
Current Login
User
This field displays the user name used to log in to the current session, the amount of
reauthentication time remaining, and the amount of lease time remaining.
Table 19 Dashboard (continued)
LABEL DESCRIPTION
