Chapter 2 The Web Configurator
NWA5000 / WAC6000 Series User’s Guide
31
About
Click About to display basic information about the NWA/WAC.
Figure 11 About
The following table describes labels that can appear in this screen.
Site Map
Click Site MAP to see an overview of links to the Web Configurator screens. Click a screen’s link to
go to that screen.
Table 12 About
LABEL DESCRIPTION
Boot Module This shows the version number of the software that handles the booting process of the
NWA/WAC.
Current Version This shows the firmware version of the NWA/WAC.
Released Date This shows the date (yyyy-mm-dd) and time (hh:mm:ss) when the firmware is released.
OK Click this to close the screen.
