LSI Corporation
- 19 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2013
Overview
Technical Support
1.8 Technical Support
For assistance installing, configuring, or running your MegaRAID 6Gb/s SAS RAID controller, contact LSI Technical
Support.
Click the following link to access the LSI Technical Support page for storage and board support:
http://www.lsi.com/about/contact/pages/support.aspx
From this page, you can email or call LSI Technical Support, or submit a new service request and view its status.
NOTE Record your controller serial number in a safe location in case you
need to contact LSI.
Documents and Downloads:
http://www.lsi.com/support/Pages/downloads.aspx?k=*
Hardware exclusive OR (XOR) assistance Yes
Direct I/O Yes
Architecture Fusion-MPT
Table 2 6Gb/s MegaRAID SATA+SAS RAID Controller Features (Continued)
Specification
MegaRAID SAS 9240, SAS 9260, SAS 9261, SAS 9265, SAS 9266, SAS 9270, SAS 9271,
SAS 9280, SAS 9285, and SAS 9286 RAID Controllers
