LSI Corporation
- 44 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2013
MegaRAID SAS RAID Controller Characteristics
6Gb/s MegaRAID SAS RAID Controller Family
3.1.5 MegaRAID SAS 9266 RAID Controllers
The MegaRAID SAS 9266-4i low-profile SAS/SATA RAID controller controls four internal SAS/SATA ports through one
SFF-8087 mini SAS 4i internal connector.
The MegaRAID SAS 9266-8i low-profile SAS/SATA RAID controller controls eight internal SAS/SATA ports through two
SFF-8087 mini SAS 4i internal connectors. This controller supports a nonvolatile CVFM02 module that connects to a
CVPM02 module to provide backup for your data in case of power loss.
NOTE The MegaRAID SAS 9266-4i RAID controller does not contain the J5B1
connector, which supports ports 4 to 7. The J5B1 connector is on the
MegaRAID SAS 9266-8i RAID controller.
J2B3 Advanced Software Options Hardware Key header 3-pin header
Enables support for the Advanced Software Options
features, which include CacheCade, FastPath, Recovery, and
SafeStore disk encryption.
J2B4 Standard Edge Card connector The RAID controller interfaces with the host system though a
standard edge card.
This interface provides power to the board and an I
2
C
interface connected to the I
2
C bus for IPMI.
J5A1 Serial Universal Asynchronous Receiver/Transmitter
(UART) connector for the expander
4-pin connector
Reserved for LSI use.
J5B1 Board-to-Board Mezzanine connector 240-pin 02 DDR3 nonvolatile memory module interface
Connects a Cache Vault Flash Module, CVFM03, directly to
the RAID controller. The CVFM03 module connects to a
Cache Vault Power Module 02, CVPM02, that is mounted on
a remote mount board.
Refer to the MegaRAID SAS 9265CV-8e RAID Controller Quick
Installation Guide for the procedure used to connect the
CVFM03 module to the CVPM02 module.
J6A1 Serial Universal Asynchronous Receiver/Transmitter
(UART) connector for the expander
4-pin connector
Reserved for LSI use.
Table 9 MegaRAID SAS 9265CV-8i RAID Controller – Jumpers and Connectors (Continued)
Jumper/
Connector
Type Description
