LSI Corporation
- 87 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2013
MegaRAID SAS RAID Controller Characteristics
Technical Specifications
The parameters for the nonoperating (such as storage and transit) environment for these controllers are as follows:
Relative humidity range is 5 percent to 90 percent noncondensing.
Temperature range:
— –40 °C to +70 °C (without BBU)
— 0 °C to +45 °C (with BBU)
3.3.4.29 Power Supply Requirements for the MegaRAID SAS 9286CV-8e RAID Controller
All power is supplied to the MegaRAID SAS 9286CV-8e RAID controller through the PCIe 3.3-V rails and the 12-V rail.
Onboard switching regulator circuitry operating from the 3.3-V rails and the 12-V rail provides the necessary voltages.
The following states determine the typical current consumption of the controller:
State 1: During a hard reset
State 2: During a disk stress test
State 3: While sitting idle at the DOS prompt
The supply voltages are 12 V ± 8 percent (from the PCI edge connector only) and 3.3 V ± 9 percent (from the PCI edge
connector only). The following table lists the power supply for the controller for each of the three states at the
different voltages.
3.3.4.30 Operating and Nonoperating Conditions for the MegaRAID SAS 9286CV-8e RAID Controller
The operating (thermal and atmospheric) conditions for the MegaRAID SAS 9286CV-8e RAID controller are as follows:
Relative humidity range is 20 percent to 80 percent noncondensing.
Airflow must be at least 200 linear feet per minute (LFPM) to avoid operating the LSISAS2208 processor above the
maximum ambient temperature.
Temperature range: +10 °C to +55 °C (with or without a Cache Vault module).
NOTE The MegaRAID SAS 9286CV-8e RAID controller supports the CVFM03
module and the CVPM02 module, but the controller does not support
BBU units.
The parameters for the nonoperating (such as storage and transit) environment for these controllers are as follows:
Relative humidity range is 5 percent to 90 percent noncondensing.
Temperature range:
— –40 °C to +70 °C (without a Cache Vault module)
— 0 °C to +55 °C (with a Cache Vault module)
Table 38 Power Supply for the MegaRAID SAS 9286CV-8e RAID Controller
PCI Edge Connector State 1 State 2 State 3
+3.3-V supply 593 mA 974 mA 963 mA
+12-V supply 598 mA 768 mA 816 mA
+3.3-V auxiliary supply 0.4 mA 0.3 mA 0.1 mA
Total Power 9.134 W 12.431 W 12.970 W
