Robomow RM200 [21/44] Zones setup

Robomow RM200 [21/44] Zones setup
21
Figure 2.2
Zones setup options
Set zone: A
Set zone: B
Work time
Learn edge
Set default edge
2.1.1
2.1.1.1
2.1.1.2
2.1.1.3
Set zone: A
Set zone: B
Work time
Learn edge
Set default edge
2.1.1
2.1.1.1
2.1.1.2
2.1.1.3
2.1 Zones setup
The ‘Zones setup’ menu allows user to set the parameters that are specific per zone.
It is possible to set up to two different zones: zone A and B, when the main zone is
Zone A.
2.1.1 Set zone: A (or B)
Allows user to set the parameters that are specific per non-Base Station zone (figure 2.2):
2.1.1.1 Work time
Allows the user the option of setting the operating time from 15 minutes up to 2 hours and ‘MAX’ which
is generally 2.5 hours, depending on grass type and condition.
2.1.1.2 Learn Edge
The default distance for edge mowing is approximately 1 to 2 rounds around the perimeter. This feature
allows the user to define a specific distance in each operating zone in order to have the mower cut the
edge at a specific distance. It will remain as a learned distance until the edge is re-learned or the ‘Set
default edge’ is selected. To learn edge distance follow the instructions below (figure 2.3):
2.1.1.3 Set Default Edge
Selecting Default Edge restores the factory default edge distance to the specific zone selected.
2.2 Settings
The ‘Settings’ menu allows the user to set the options that refer to the Robomow itself and are
common to all zones (figure 2.1).
2.2.1 Child Guard
Child guard is a feature that when activated will help deter use by young children and other
unauthorized people. It will prevent operation to those not familiar with the mower. The key sequence to
unlock the guard for operation is pressing the ‘UP’ arrow key and then the ‘STOP’ key to unlock the
controls. Two minutes of inactivity will re-lock the keys.
It is strongly recommended to use the “Child Guard” menu option in order to prevent operation
by children or others who are not familiar with the safe operation of the Robomow.
2.2.2 Anti-Theft
The anti-theft system provides the user a disabling function that will prevent anyone from using or
driving the Robomow unless they have the valid code to enter. You will be prompted to enter a four-digit
code of your choice to use as your personal security code. Use the scroll arrows in order to change
each digit position to a different number and then press
‘GO’ to move to the next digit to select. You will
find a place to record your personal security code in Chapter 8 of this manual. Be sure to record your
code for future reference.
To change the password, choose the
‘Change code’ option under the ‘Anti theft’ menu. You will be
promoted to enter your old password before setting the new one.
Figure 2.3
Learn edge
Set zone: A
Press GO
Scroll DOWN once to
‘Learn edge’ option
Scroll to the zone of which
you want to learn the edge
distance and press ‘GO’
Press ‘GO’ to start
the learning process
Work time
Press GO
Learn edge
Press GO
Learning edge
STOP to set
While driving around the perimeter.
Follow the mower and press the
‘STOP’ button when the desired
distance has been reached.
Set zone: A
Press GO
Set zone: A
Press GO
Scroll DOWN once to
‘Learn edge’ option
Scroll to the zone of which
you want to learn the edge
distance and press ‘GO’
Press ‘GO’ to start
the learning process
Work time
Press GO
Work time
Press GO
Work time
Press GO
Learn edge
Press GO
Learn edge
Press GO
Learn edge
Press GO
Learning edge
STOP to set
Learning edge
STOP to set
Learning edge
STOP to set
While driving around the perimeter.
Follow the mower and press the
‘STOP’ button when the desired
distance has been reached.
