Robomow RM200 [30/44] Message displayed probable cause event corrective user action
![Robomow RM200 [30/44] Message displayed probable cause event corrective user action](/views2/1172824/page30/bg1e.png)
30
Message
Displayed
Probable Cause/Event Corrective/User Action
- An unknown fault has occurred and user
help is required
- Manually drive/carry the mower away
from this particular area and restart
operation.
Start elsewhere
- Drive wheel motors have been working
under a severe load during automatic or
manual operation.
- Check to insure the mower is not stuck,
allowing the drive wheels to slip.
- Check the ground for holes or
indentions, where the mower has
stopped and fill it with dirt and level off.
- Check the drive wheels are free to
rotate and nothing block them.
- Remove the mower away from this
particular point and restart operation.
Start inside
- Automatic operation is initiated while
Robomow is placed out of the perimeter wire
lope.
- Place the mower inside the lawn and
press the ‘GO’ button.
- Robomow get stuck in place with no succeed
to continue driving.
- Check the ground for holes or
indentions, where the mower has
stopped and fill it with dirt and level off
– especially in the area close to the
perimeter, where the Robomow turns in
place.
Stuck in place
- Robomow has slipped out of the perimeter
wire lope because of slopping area or wet
grass.
- Robomow has difficulty to turn in place
because the front wheel has fallen into hole
or indention and it caused the mower to turn
in place without detecting wire or bumper.
- Confirm the area is not too sloppy and
make sure to work in dry condition.
- Check the perimeter wire is not too
close to the edge – remove if required.
- Conform the mowing deck is not set too
low.
- There is an option to drive back to the
lawn in reverse before Robomow
perform the turn in place (contact your
service dealer for details).
Switch off
before lifting
- The user carries Robomow manually while
the main switch button is on.
- Switch off the main switch button before
carrying Robomow.
Time and date
- Displayed every time the batteries fuse is
taken out of the mower (reset operation)
- Set real time clock (day and hour) and
the date.
Time completed
- The operating time set for that zone has
been reached.
- Connect to the charger if all mowing has
been completed for the day.
Waiting for
signal…
- Robomow has stopped the operation,
because there is no signal detected.
- Check the power to the Base Station.
- There is electrical power interruption.
There is no need to do anything –
Robomow will renew automatically the
operation if the power will come back
within an hour from the break; if the
power will come back after more than
one hour, Robomow will drive back to
the Base Station for charging, but will
not renew the operation and mowing.
