32
Problem
Encountered
Probable Cause/Event Corrective/User Action
LCD display is in a
foreign language.
- The language setting was changed or
not correctly set.
- Place the mower out of the Base Station
and follow the sequence listed;
- Press ‘STOP’ button few times to confirm it
is on the main display
- Press ‘UP’ button twice
- Press ‘GO’ button once
- Press ‘Down’ arrow button once
- Press ‘GO’ button once
- Press ‘Down’ arrow button 4 times
- Press ‘GO’ button once
- Using the arrow, scroll to the correct
language
- Press ‘GO’ to confirm this selection
- Important! It is possible to see the last 10 battery run times and the battery voltage at
the beginning of the operation in the ‘Information’ menu (refer to paragraph 2.3.2)
- Battery is not fully charged at the
beginning of the operation
- Confirm the battery icon is fully and not
changed (while charging in the Base
Station) or ‘Ready keep charging’ message
is displayed (while charging through power
supply) prior the operation.
- ‘Work Time ‘ for that zone is set to
specific time and not to ‘MAX’
- ‘Work time’ can be changed under ‘Zones
setup’ menu
- Grass is extremely over grown or very
wet.
- Raise cutting height.
- Always mow the grass frequently enough to
prevent over growth.
- CAUTION – Remove battery fuse before
lifting the mower
- Inspect blades for foreign material or debris
preventing rotation.
- Clean out accumulated grass clippings
using a wooden stick.
Short run time,
operates less time
than normal
- Batteries are reaching a normal end of
life state.
- Replace batteries.
- Confirm that the time in the mower is
set correctly (hour and date)
- Set the time (See paragraph 2.2.3)
Robomow operates
at the wrong times
- The ‘GO’ button was pressed with no
meaning, by someone or by a pet
(‘Last stop cause’ under the
‘Information’ menu should be 805).
- To prevent unintended operation you can
activate the ‘Child guard’ or the ‘Anti theft’
options, which requires pressing of few
buttons in order to start the operation.
- Wire disconnected from perimeter
switch or from the Base Station.
- Confirm wire is plugged in and wire leads
are firmly attached.
- Perimeter wire cut
- Walk along perimeter, including islands and
look for obvious cuts or breaks in the wire.
Repair with Robomow wire splice
connectors.
'Cut wire’ indicator
flashing on
Perimeter Switch
or
the Base Station
beeps continuously
for 'Cut wire’
- Poor connections
- Check and repair all loose/poor or corroded
connections.
