Table 10 summarizes features of supported drive controllers.
Table 10. Drive controller features and specifications summary
Feature Integrated
6 Gb SATA
(non-RAID)
M1215 M5210 N2215
Part number None 46C9114 46C9110 47C8675
Form factor Onboard PCIe low profile PCIe low profile PCIe low profile
Controller chip Not applicable LSI SAS3008 LSI SAS3108 LSI SAS3008
Host interface Not applicable PCIe 3.0 x8 PCIe 3.0 x8 PCIe 3.0 x8
Port interface 6 Gbps SATA 12 Gbps SAS 12 Gbps SAS 12 Gbps SAS
Number of ports 8 8 8 8
Port connectors 2x SATA x4 2x Mini-SAS HD x4
(SFF-8643)
2x Mini-SAS HD x4
(SFF-8643)
2x Mini-SAS HD x4
(SFF-8643)
Drive interface SATA SAS, SATA SAS, SATA SAS, SATA
Drive type HDD HDD, SSD, SED HDD, SSD, SED HDD, SSD
Drive form factor SFF, LFF SFF, LFF SFF, LFF SFF, LFF
Hot-swap drives No Yes Yes Yes
Max devices 8 32 (RAID); 64 (JBOD) 240 1024
RAID levels None 0/1/10;
Optional 5/50 (00AE930)
0/1/10; Optional 5/50
(RAID 5 FoD, 47C8708,
or cache upgrades);
Optional 6/60 (47C8706)
None
JBOD mode Yes Yes Yes (without cache) Yes
Cache None None 1 GB no backup (47C8656)
1 GB flash (47C8660)
2 GB flash (47C8664)
4 GB flash (47C8668)
None
SafeStore No Yes (with RAID 5 upgrades) Yes (with RAID 5 upgrades) No
FastPath No No Optional (47C8710) No
CacheCade No No Optional (47C8712) No
For more information, see the list of Product Guides in the RAID adapters category:
https://lenovopress.com/servers/options/raid
Lenovo System x3650 M5 22
