Microcode Support
Keeping microcode current helps prevent hardware failures and security exposure. There are two
levels of service: analysis of the installed base and analysis and update where required. Offerings
vary by country and can be bundled with other warranty upgrades and extensions.
Remote Technical Support Services (RTS)
RTS provides comprehensive technical call center support for covered servers, storage, operating
systems, and applications. Providing a single source for support of hardware and software issues,
RTS can reduce problem resolution time, decreasing the cost to address technical problems and
increasing uptime. Offerings are available for Windows, Linux, IBM Systems Director, VMware,
Microsoft business applications, and Lenovo System x storage devices, and IBM OEM storage
devices.
Regulatory compliance
The server conforms to the following regulations:
FCC - Verified to comply with Part 15 of the FCC Rules, Class A
Canada ICES-003, issue 5, Class A
UL/IEC 60950-1
CSA C22.2 No. 60950-1
NOM-019
Argentina IEC60950-1
Japan VCCI, Class A
Australia/New Zealand AS/NZS CISPR 22, Class A; AS/NZS 60950.1
China CCC GB4943.1, GB9254 Class A, GB17625.1
Taiwan BSMI CNS13438, Class A; CNS14336-1
Korea KN22, Class A; KN24
Russia, Belorussia and Kazakhstan, TR CU 020/2011 (for EMC) and TR CU 004/2011 (for safety)
IEC 60950-1 (CB Certificate and CB Test Report)
CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2, EN61000-3-3)
CISPR 22, Class A
TUV-GS (EN60950-1 /IEC60950-1,EK1-ITB2000)
RoHS Directive
External storage expansion
The x3650 M5 server supports attachment to external storage expansion enclosures, such as the Lenovo
Storage E1000 series, by using the ServeRAID M5225 SAS/SATA Controller. The server can also be
attached to supported external storage systems, such as the Lenovo Storage S2200 and S3200, using the
supported HBAs.
Table 27 shows the RAID controllers and options.
Table 27. RAID controllers and options for external disk storage expansion
Part
number
Feature
code
Description Maximum
supported
Standard models
where used
12 Gb RAID controllers
00AE938 A5ND ServeRAID M5225-2GB SAS/SATA Controller 3 -
Feature on Demand (FoD) upgrades for the M5225
47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1* -
47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator 1* -
47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler 1* -
* One FoD upgrade for the M5225 activates the feature on all M5225 controllers installed in a server.
Lenovo System x3650 M5 42
