External backup units
Table 33 lists the external backup options that are offered by Lenovo that can be used in x3650 M5
solutions.
Table 33. External backup options
Part number Description
External tape enclosures
61901UX IBM Multimedia Backup Enclosure
Backup drives for IBM Multimedia Backup Enclosure
00NV402 6190 HH LTO5 SAS Tape Drive
00NV404 6190 HH LTO6 SAS Tape Drive
00NV406 6190 RDX 3.0 Dock/320GB Cartridge Bundle
00NV407 6190 RDX 3.0 Dock/500GB Cartridge Bundle
00NV408 6190 RDX 3.0 Dock/1.0TB Cartridge Bundle
00NV455 6190 RDX 3.0 Dock/2.0TB Cartridge Bundle
External RDX USB drives
362532Y RDX External USB 3.0 Dock with 320GB Cartridge
362550Y RDX External USB 3.0 Dock with 500GB Cartridge
36251TY RDX External USB 3.0 Dock with 1TB Cartridge
External SAS tape backup drives
6160S5E IBM TS2250 Tape Drive Model H5S
6160S6E IBM TS2260 Tape Drive Model H6S
6160S6X IBM TS2360 Tape Drive Model S63
6160S7E IBM TS2270 Tape Drive Model H7S
External SAS tape backup autoloaders
6171S4R IBM TS2900 Tape Autoloader w/LTO4 HH SAS
6171S5R IBM TS2900 Tape Autoloader w/LTO5 HH SAS
6171S6R IBM TS2900 Tape Autoloader w/LTO6 HH SAS
6171S7R IBM TS2900 Tape Autoloader w/LTO7 HH SAS
External tape backup libraries
61732UL IBM TS3100 Tape Library Model L2U
61734UL IBM TS3200 Tape Library Model L4U
Fibre Channel backup drives for TS3100 and TS3200 Tape Libraries
00NA101 6173 LTO Ultrium 4 Fibre Channel Drive Sled
00NA103 6173 LTO Ultrium 4 Half High Fibre Drive Sled
00NA107 6173 LTO Ultrium 5 Fibre Channel Drive
00NA113 6173 LTO Ultrium 5 Half High Fibre Drive Sled
00NA115 6173 LTO Ultrium 6 Fibre Channel Drive
00NA119 6173 LTO Ultrium 6 Half High Fibre Drive Sled
00WF765 6173 LTO Ultrium 7 Fibre Channel Drive
00WF769 6173 LTO Ultrium 7 Half High Fibre Drive Sled
SAS backup drives for TS3100 and TS3200 Tape Libraries
00NA121 6173 LTO Ultrium 4 SAS Drive Sled
Lenovo System x3650 M5 46
