Lenovo x3650 m5, 5462c2g [38/54] Operating systems
![Lenovo x3650 m5, 5462c2g [38/54] Operating systems](/views2/1173103/page38/bg26.png)
IBM Security Key Lifecycle Manager for System x SEDs - FoD (SKLM - FoD) is an optional feature,
available in System x environments, that centralizes, simplifies, and automates the data encryption key
management process to help minimize risk and reduce operational costs. SKLM - FoD offers a simple and
robust solution for key storage, key serving, and key lifecycle management for self-encrypting drives (SEDs)
in local and distributed System x environments. With the x3650 M5, the Feature on Demand (FoD) upgrade
can be configured with the ServeRAID M5210 and M1215 RAID controllers paired with SEDs.
Table 24 lists SKLM-FoD part numbers.
Table 24. Security Key Lifecycle Manager - FoD part numbers
Part
number
Feature
code
Description Maximum
supported
United States, Canada, Asia Pacific and Japan
00D9998 A5U1 IBM SKLM for System x w/SEDs - FoD per Install w/1Yr S&S 1
00D9999 AS6C IBM SKLM for System x w/SEDs - FoD per Install w/3Yr S&S 1
Latin America, Europe, Middle East and Africa
00FP648 A5U1 IBM SKLM for System x w/SEDs - FoD per Install w/1Yr S&S 1
00FP649 AS6C IBM SKLM for System x w/SEDs - FoD per Install w/3Yr S&S 1
Rack installation
Table 25 lists the rack installation options that are available for the x3650 M5 server.
Table 25. Rack installation options
Part
number
Feature
code
Description Maximum
supported
00FK656 A5FV System x Enterprise Slides Kit 1
00KA500 A5FW System x Gen-II Universal Slides Kit 1
00MW239 ATLQ System x M5 Custom Rail Kit 1
00FK622 A5FX System x Enterprise 2U Cable Management Arm (CMA) 1*
00FK660 A5G0 System x3650 M5 Lockable Bezel 1
* The System x CMA requires the Enterprise Slides Kit (00FK656) or Universal Slides Kit (00KA500). The Custom Rail Kit
(00MW239) is not supported with the CMA.
Note: The System x Enterprise Slides Kit, part number 00FK656, is included with the standard models that
are listed in Table 2 and Express and TopSeller models that are listed in Table 3.
Operating systems
Lenovo System x3650 M5 38
