EXP2512 and EXP2524
The external SAS cables listed in Table 29 support connectivity between external expansion enclosures
and the ServeRAID M5225 SAS/SATA Controller.
Table 29. External SAS cables for external storage expansion enclosures
Part number Description Maximum quantity supported per
one enclosure
Server to Expansion enclosure connectivity (Mini-SAS HD x4 to Mini-SAS x4)
00MJ162 0.6m SAS Cable (mSAS HD to mSAS) 1
00MJ163 1.5m SAS Cable (mSAS HD to mSAS) 1
00MJ166 3m SAS Cable (mSAS HD to mSAS) 1
Expansion enclosure to Expansion enclosure connectivity (Mini-SAS x4 to Mini-SAS x4)
00WC017 1 m SAS Cable 1
00WC018 3 m SAS Cable 1
Table 30 lists drives that are supported by EXP2512 external expansion enclosures.
Table 30. Drive options for EXP2512 external expansion enclosures
Part number Description Maximum quantity supported per
one enclosure
3.5" NL SAS HS HDDs
00NC555 2TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
00NC557 3TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
00NC559 4TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
Table 31 lists hard disk drives that are supported by EXP2524 external expansion enclosures.
Table 31. Drive options for EXP2524 external expansion enclosures
Part number Description Maximum quantity supported per
one enclosure
2.5" NL SAS HS HDDs
00NC571 1TB 7,200 rpm 6Gb SAS NL 2.5" HDD 24
2.5" SAS HS HDDs
00NC561 146GB 15,000 rpm 6Gb SAS 2.5" HDD 24
00NC563 300GB 15,000 rpm 6Gb SAS 2.5" HDD 24
00NC565 600GB 10,000 rpm 6Gb SAS 2.5" HDD 24
00NC567 900GB 10,000 rpm 6Gb SAS 2.5" HDD 24
00NC569 1.2TB 10,000 rpm 6Gb SAS 2.5" HDD 24
2.5" SAS HS SSDs
00NC573 200GB 6Gb SAS 2.5" SSD 24
00NC575 400GB 6Gb SAS 2.5" SSD 24
External disk storage systems
Lenovo System x3650 M5 44
