Princess 117001 [11/52] Description fig a
![Princess 117001 [11/52] Description fig a](/views2/1178021/page11/bgb.png)
11
EN
Clean the outside of the appliance with a •
soft, damp cloth. Thoroughly dry the outside
of the appliance with a clean, dry cloth.
Clean the baking plates after each use:•
- Remove the baking plates.
- Remove any residues with a paper towel.
- Clean the baking plates with a soft,
damp cloth and a few drops of washing-
up liquid. Rinse the baking plates under
running water. Thoroughly dry the
baking plates.
- Mount the baking plates.
Description (fig. A)
Your 117001/117002/117011 Princess grill has
been designed for grilling food without using
fat. The appliance is equipped with removable
baking plates with a non-stick coating. The
appliance is suitable for indoor use only. The
appliance is suitable for domestic use only.
1. Temperature indicator
2. Handgrip
3. Lid
4. Lid latch
5. 117001/117002/117011: Baking plate
6. 117002: Baking plate (sandwiches)
7. 117002: Baking plate (waffles)
8. Release button (baking plate)
Initial use
Before you proceed, we need you to pay
attention to the following notes:
- Make sure that there is sufficient space
around the appliance to allow heat to
escape and provide sufficient ventilation.
Clean the appliance. Refer to the section •
"Cleaning and maintenance".
Clean the accessories. Refer to the section •
"Cleaning and maintenance".
Place the appliance on a stable and flat •
surface.
Insert the mains plug into the wall socket. •
The temperature indicator comes on. The
appliance starts heating.
After use, remove the mains plug from the •
wall socket and allow the appliance to cool
down completely.
Note: If you switch on the appliance for the
first time, the appliance may emit a little
smoke and a characteristic smell for a short
period. This is normal operation.
Use
Before you proceed, we need you to pay
attention to the following notes:
- Before assembly or disassembly, remove
the mains plug from the wall socket and
wait until the appliance has cooled down.
- Do not let metal cutlery touch the baking
plates to prevent damage to the non-stick
coating.
Grilling food (fig. A)
Prepare the food.•
Place the appliance on a stable and flat •
surface.
If necessary, clean the baking plates •
(5/6/7) with a soft, damp cloth. Mount the
baking plates (5/6/7) until the release
buttons (8) click into place.
Close the lid (3). Make sure that the lid •
latch (4) locks into place.
To switch on the appliance, insert the •
mains plug into the wall socket. The
temperature indicator (1) comes on. The
appliance starts heating.
The temperature indicator (1) goes off •
when the heating elements have reached
the required temperature. The appliance is
ready for use.
Release the lid latch (4) and open the lid •
(3).
Place the food onto the lower baking plate •
(5/6/7).
Close the lid (3). Make sure that the lid •
latch (4) locks into place. The temperature
indicator (1) comes on.
The temperature indicator (1) goes off •
when the heating elements have reached
the required temperature.
Grill the food until it is ready for •
consumption.
Stay close to the appliance in order to •
check from time to time whether the food
is ready and to make sure that the food
does not burn.
