User instructions
44
EN
EN
User instructions
45
SETTING THE WASHING PROGRAM AND SWITCHING ON
To select the most suitable program for the dishes to be washed refer to the table
below, which indicates the most appropriate program according to dish type and
degree of soiling.
After using the table to identify the most appropriate washing program:
• press the ON/OFF button (1) and wait for the PROGRAM INDICATOR LIGHT
(2) to illuminate;
• keep pressing the PROGRAM SELECTION button (3) until the indicator light
corresponding to the desired program illuminates;
• close the door; after about 2” the program will start. While it is in progress, the
relative LIGHT will ash (indicating that the program is being executed).
PROGRAMME
LOAD
CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
DURATION CONSUMPTION (3)
DETERGENT
GRAMS
MINUTES
(2)
WATER
(LITRES)
(1)
POWER
(KW)
(2)
Nr Symbol Name
1
SOAK
Mixed dishes
awaiting
washing
Cold rinse (to prevent
dirt from drying).
15’ 3,5 0,01 -
2
QUICK
Dishes and
glasses with
light dirt
Wash at 38°C
Cold rinse
Rinse at 58°
45’ 10 0,8 20
3
AUTO 50
Mixed dishes,
normal dirt
Cold prewash and hot
wash (about 50°C)
depending on type of dirt
Cold rinse
Rinse at 68°
Dry
(**) (**) (**) 30
4
NORMAL
Mixed dishes
and pans,
normal dirt
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 68°
Dry
105’ 14 1,3 30
5
STRONG
AND FAST
Mixed dishes,
normal dirt
which has not
dried
Wash at 65°C
Cold rinse
Rinse at 70°
50’ 10 1,2 30
50�
60�
50�
50�
50�
50�
50�
