Smeg STO905 [9/35] Description of the controls
![Smeg STO905 [9/35] Description of the controls](/views2/1017902/page9/bg9.png)
42
EN
EN
43
3. Description of the controls
3.1 Upper panel
All the dishwasher controls are grouped on the upper panel. Switch-on,
programming, switch-off etc. procedures are only possible when the door is
open.
1
ON/OFF BUTTON
Pressing this button energises the appliance.
2
SELECTED PROGRAM INDICATOR LIGHTS
Illumination of this light denotes the program selected and theoccurrence
of a fault (troubleshooting).
3
PROGRAM SELECTION BUTTON
By pressing this button in sequence it is possible to select the desired
program.
4
SALT WARNING LIGHT
Illumination of this light signals that salt container is empty.
5
RINSE AID WARNING LIGHT
Illumination of this light signals that rinse aid dispenser is empty.
6
EXTRA PROGRAM BUTTON
This button gives access to the one of the ve extra programs (see table).
7
EXTRA PROGRAM LIGHT
Illuminates to indicate that one of the ve extra programs (see table) is
going to be executed.
50�
60�
User instructions
