Smeg STO905 [8/35] Installation instructions
![Smeg STO905 [8/35] Installation instructions](/views2/1017902/page8/bg8.png)
40
EN
EN
41
In the event of damage to the supply cord, have it replaced by the an
Authorized Technical Service Centre in order to avoid any risk.
If this lamp needs changing, contact the manufacturer or an Authorised
Service Centre.
The lamp must be of the same type and have the same characteristics as
the one already installed (see dataplate next to the lamp holder).
WHEN CLEANING AND MAINTAINING THE APPLIANCE:
BEFORE CARRYING OUT ANY WORK, ALWAYS UNPLUG THE APPLIANCE
FROM THE ELECTRICAL SUPPLY OR SWITCH OFF THE ALL-POLE
DISCONNECTION DEVICE.
WARNING! Some components inside the appliance are intentionally
electrically live even with the ON/OFF switch turned to off.
Before any repair operation, disconnect the appliance from the electrical
mains.
FOR UK ONLY:
THIS APPLIANCE MUST BE EARTHED.
Fuse replacement
If the mains lead of this appliance is tted with a
BS 1363A 13amp fused plug, to change a fuse
in this type of plug use an A.S.T.A. approved
fuse to BS 1362 type and proceed as follows:
1. Remove the fuse cover A and fuse B.
2. Fit replacement 13A fuse into fuse cover.
3. Re t both into plug.
The fuse cover must be re tted when changing a fuse if the fuse cover is
lost the plug must not be used until a correct replacement is tted.
Correct replacement are identi ed by the colour insert or the colour
embossed in words on the base of the plug.
Replacement fuse covers are available from your local electrical store.
Installation Instructions
Installation instructions
In the event of damage to the supply cord, have it replaced by the
an Authorized Technical Service Centre in order to
WHEN CLEANING AND MAINTAINING THE APPLIANCE:
BEFORE CARRYING OUT ANY WORK, ALWAYS UNPLUG THE APPLIANCE
FROM THE ELECTRICAL SUPPLY OR SWITCH OFF THE ALL-POLE
DISCONNECTION DEVICE.
FOR GREAT BRITAIN ONLY:
THIS APPLIANCE MUST BE EARTHED.
Fuse replacement
If the mains lead of this appliance is fitted
with a
BS 1363A 13amp
fused plug, to
change a fuse in this type of plug use an
A.S.T.A.
approved fuse to
BS 1362
type
and proceed as follows:
1.
Remove the fuse cover
A
and fuse
B
.
2.
Fit replacement 13A fuse into fuse
cover.
3.
Refit both into plug.
The fuse cover must be refitted when changing a fuse and if the fuse
cover is lost the plug must not be used until a correct replacement is
fitted.
Correct replacement are identified by the colour insert or the colour
embossed in words on the base of the plug.
Replacement fuse covers are available from your local electrical store.
