![Smeg STA4648D [24/28] Cleaning and maintenance](/views2/1017946/page24/bg18.png)
User instructions
31
4. Cleaning and maintenance
Before carrying out any work, always disconnect the appliance from the electrical power
supply.
4.1 General warnings and recommendations
Avoid the use of acidic or abrasive detergents.
Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened
with water or with a normal detergent suitable for painted surfaces.
Clean the door gaskets with a damp sponge.
Periodically (once or twice a year) it is advisable to clean the tank and gaskets, using a soft cloth
and water to remove any deposits.
CLEANING THE WATER INTAKE FILTER
The water intake filter
A
located at the outlet of the water supply tap needs to be cleaned
periodically.
After having closed the water supply tap, unscrew the end of the water intake hose, remove the
filter
A
and clean it delicately under running water. Reassemble filter
A
in its seat and carefully
screw the water intake hose back into position.
CLEANING THE SPRAY ARMS
The spray arms can be easily removed for periodic cleaning of
the nozzles, to prevent possible clogging. Wash them under
running water and carefully replace them in their seats,
checking
that their rotary movement is in no way impeded.
To remove the
upper
spray arm, unscrew locking ring
R
.
CLEANING THE SPRAY ARM, TRAVELLING VERSION
To remove the TRAVELLING spray arm, take hold of it and raise it to release both the spray arm
and the pipe from the tank, then detach the spray arm from the pipe. Wash both the pipe and the
spray arm in running water, re-attach the spray arm to the pipe and return the assembly to the seat
provided in the tank.
Once the assembly has been put back in place, check that the spray arm turns freely (turn
through a couple of revolutions by hand) and that the pipe is able to travel without
impediments.
Otherwise, check that it has been fitted correctly.
