User instructions
1. Description of the controls
1.1 Upper panel
All the dishwasher controls are grouped on the upper panel.
1
ON/OFF BUTTON
Pressing this button energises the appliance.
2
SELECTED PROGRAM INDICATOR LIGHTS
Illumination of this light denotes the program selected and the occurrence of a
fault (troubleshooting).
3
PROGRAM SELECTION BUTTON
By pressing this button in sequence it is possible to select the desired
program.
4
SALT WARNING LIGHT
(certain models only)
Illumination of this light signals that salt container is empty.
5
RINSE AID WARNING LIGHT
(certain models only)
Illumination of this light signals that rinse aid dispenser is empty.
6
DELAYED START BUTTON
(certain models only)
Pressing this button in sequence delays the start of the program by 3, 6 or 9
hours.
7
DELAYED START LIGHTS
(certain models only)
Illuminate to show that start delayed by 3, 6 or 9 hours has been set.
8
"3/1" OPTION BUTTON
(certain models only)
Press this button to activate the option for use of 3/1 products.
9
"3/1" OPTION LIGHT
(certain models only)
Illuminates to indicate that the function is activated.
SETTING THE WASHING PROGRAM AND SWITCHING ON
To select the most suitable program for the dishes to be washed refer to the
table below, which indicates the most appropriate program according to dish
type and degree of soiling.
