User instructions
After using the table to identify the most appropriate washing program:
•
press the
ON/OFF
button
(1)
and wait for the
PROGRAM
INDICATOR LIGHT (2)
to illuminate;
•
keep pressing the
PROGRAM SELECTION
button
(3)
until the
indicator light corresponding to the desired program illuminates;
•
close the door; after about
2"
the program will start. While it is in
progress, the relative
LIGHT
will flash (indicating that the program is
being executed).
DURATION CONSUMPTION
PROGRAMME,
NUMBER & SYMBOL
LOAD CROCKERY
AND CUTLERY
PROGRAM
PROGRESS
MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
1
SOAK
Pans and dishes
awaiting
a further wash
Cold prewash
9' 5
_
2
DELICATE
Wash immediately
after use for dishes
with light dirt
Wash at 45°C
Cold rinse
Rinse at 68°C
Dry
59' 12 0,90
3
ECO (*)
EN 50242
Wash immediately
after use for dishes
with normal dirt
Wash at 50°C
Cold rinse
Rinse at 65°C
Dry
125'
(**)
13 1,01
4
NORMAL
Dishes
with normal dirt
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 68°C
Dry
80' 17 1,20
5
INTENSIVE
Very dirty pans and
dishes (except
delicate items)
Prewash at 45°C
Wash at 70°C
2 cold rinses
Rinse at 70°C
Dry
105' 20 1,50
Only
run the soak program with half loads.
(*) Reference program as per EN 50242 standard.
(**) The duration of the ECO program (EN 50242) for AAA moodels (see energy
label) is
175'
.
(–) Not present.
(1) Average power consumption with the softener set on
level 2
.
(2) The cycle duration and power consumption may vary according to the water and
room temperatures, and the type and amount of dishes.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.
