21
Preparations
1
1 Preparations
Actual models because of functional variation, Function key guide options will be different.
Please run the corresponding function based on the actual icon and description.
When the monitor displays nothing (i.e. Power saving mode or Non-signal mode), 2 direct keys for
control source and power could be used as below.
When the monitor displays the Main menu the JOG Button could be used as below.
Select [ ] by moving the JOG button in the Function Key Guide
screen.
Press to enable or disable Eye Saver Mode
.
The items below are not available if the Eye Saver Mode function is
enable.
Picture Game Mode, Bright, Brightness, Color
System Eco Saving Plus
Selects [ ] to turn the Monitor off by moving the JOG button in the
Function Key Guide screen.
JOG Button
Power saving/Non-signal mode
UP
Source Change
Down
PRESS(ENTER) for 2 seconds Power Off
JOG Button
Action
UP/DOWN - Move the option
LEFT
- Exit the Main menu.
- Close Sublist without saving value.
- Value decreases in the slider.
RIGHT
- Move to next depth.
- Value increases in the slider.
ENTER
- Move to next depth.
- Save the value and close Sublist.
