Screen Setup
3
3 Screen Setup
4:3: Display the picture with an aspect ratio of 4:3. Suitable for videos and standard broadcasts.
16:9: Display the picture with an aspect ratio of 16:9.
Screen Fit: Display the picture with the original aspect ratio without cutting off.
Changing the screen size is available when the following conditions are satisfied.
The function may not be supported depending on the ports provided with the product.
A digital output device is connected using the HDMI cable.
A digital output device is connected using the DP cable.
The input signal is 480p, 576p, 720p, or 1080p and monitor can display normally
(Not every model can support all of these signals.).
This can only be set when the external input is connected through HDMI, DP and
PC/AV Mode
is set to AV.
4 Move to the desired option controlling the JOG button UP/DOWN and press the JOG button.
5 The selected option will be applied.
In AV mode
100
75
60
50
50
2200
0
Eye Saver Mode
Game Mode
Response Time
Picture Size
Screen Adjustment
Choose the size and
aspect ratio of the
picture displayed on
screen.
4:3
16:9
Screen Fit
Off
Off
