Samsung s27e591c [86/101] Standard signal mode table

Specifications

9 Specifications

9.3 Standard Signal Mode Table

 This product can be set to only one resolution for each screen size to obtain the optimum picture

quality due to the nature of the panel. Therefore, a resolution other than the specified resolution

may degrade the picture quality. To avoid this, it is recommended that you select the optimum

resolution specified for the screen size of your product.

 Check the frequency when you exchange a CDT monitor (connected to a PC) for an LCD monitor.

If the LCD monitor does not support 85 Hz, change the vertical frequency to 60 Hz using the CDT

monitor before you exchange it with the LCD monitor.

If a signal that belongs to the following standard signal modes is transmitted from your PC, the screen will

automatically be adjusted. If the signal transmitted from the PC does not belong to the standard signal

modes, the screen may be blank even though the power LED turns on. In such a case, change the

settings according to the following table by referring to the graphics card user manual.

Synchronization Horizontal Frequency 30 – 81 kHz

Vertical Frequency 56 – 72 Hz

Resolution Optimum Resolution 1920 x 1080 @ 60 Hz

Maximum Resolution 1920 x 1080 @ 60 Hz

Resolution

Horizontal

Frequency

(kHz)

Vertical

Frequency

(Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1280 x 720 45.000 60.000 74.250 +/+

VESA, 1280 x 800 49.702 59.810 83.500 -/+

VESA, 1280 x 1024 63.981 60.020 108.000 +/+

VESA, 1440 x 900 55.935 59.887 106.500 -/+

VESA, 1600 x 900 (RB) 60.000 60.000 108.000 +/+

VESA, 1680 x 1050 65.290 59.954 146.250 -/+

VESA, 1920 x 1080 67.500 60.000 148.500 +/+
