EXPANSION PORTS MOUNTING
46
Parts list and description
Part Description Number
1 Modem CGU 04i motherboard 1
2 CGU 04i box top part 1
3 CGU 04i box bottom part 1
4 CGU 04i rear head 1
5 CGU 04i front head 1
6 Expansion port 1
7 Distant columns for expansion port PORT2 mounting to motherboard 3
8 Screw for box completion 2
