11
9
Top Panel Controls
q STANDBY/ON switch ................................. 15
w MASTER VOLUME control ........................15
e DEMO button .............................................15
r RECORD button.................17, 25, 78, 92, 96
t DIRECT ACCESS button .....................21, 24
y DSP button.................................................49
u FAST/SLOW button ................................... 49
i TOUCH button .........................................120
o SUSTAIN button .........................................30
!0 HARMONY/ECHO button ..........................50
!1 BACK button, NEXT button ........................17
!2 LCD display ................................................ 16
!3 VOICE CHANGE button.............................75
MIXER button.............................................76
!4 TRACK 1 - 16 buttons .......................... 37, 70
!5 FUNCTION button........................17, 77, 118
!6 SONG button..................................17, 25, 68
!7 STYLE button................................. 17, 25, 32
!8 VOICE L button ..........................................28
!9 VOICE R1 button ....................................... 27
@0 VOICE R2 button ....................................... 27
@1 ACMP ON/OFF button ......................... 25, 33
@2 FINGERING button ....................................38
@3 TEMPO/TAP button .................................... 36
@4 TRANSPOSE button ..................................30
@5 ACMP/SONG VOLUME button ............37, 70
@6 PART ON/OFF
VOICE L button .....................................28
VOICE R1 button .................................. 27
VOICE R2 button .................................. 27
@7 Number buttons
[1]-[0], [-/NO], [+/YES] ........................... 20
@8 EXIT button ................................................ 17
@9 Data dial .....................................................20
#0 DISK LOAD button ...............................17, 62
#1 DISK SAVE button ............................... 17, 60
#2 DISK UTILITY button .....................17, 64, 67
#3 SYNC STOP button ................................... 41
#4 SYNC START button .................................. 33
#5 START/STOP button ............................ 32, 69
#6 INTRO button .............................................34
#7 MAIN/AUTO FILL A button .........................34
#8 MAIN/AUTO FILL B button .........................34
#9 ENDING/rit. button .....................................34
$0 REGISTRATION MEMORY buttons ...........54
$1 ONE TOUCH SETTING buttons ................ 42
$2 MULTI PAD buttons ....................................43
$3 Disk Drive...................................................58
$4 PITCH BEND wheel ...................................30
Panel Controls and Terminals
Rear Panel Controls
$5 PHONES/OUTPUT jack............................. 13
$6 FOOT SWITCH jack...................................13
$7 TO HOST connector ................................107
$8 HOST SELECT switch .............................110
$9 MIDI IN/OUT connectors.......................... 107
%0 DC IN 10-12V jack .....................................12
