Enter the desired name for the bank.
Use the keyboard to enter the name (page 21).
Up to eight letters or characters can be used.
11
Press the [RECORD] button to exit from the Record mode.
Clearing User Pad Data
1
-
7
Use the same operation as in “Chord Match” above.
8
Select “Clear”.
Use the data dial, the [+/YES] button or the [-/NO] button.
10
Select the Pad number to be cleared.
Use the data dial, the [+/YES] button or the [-/NO] button.
To clear the data from all four pads, select “All”.
11
Press the [NEXT] button.
12
Execute the Clear operation.
Press the [+/YES] button to execute the Clear operation.
To abort the Clear operation, press the [-/NO] button.
13
Press the [RECORD] button to exit from the Record mode.
Multi Pad Recording
P.Name=UserPad2
Clr Pad=Pad1
Clear OK?
9
Press the [NEXT] button.
Ed Menu=Clear
The Clear operation is completed...
Completed
