277
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
*1. The following modes can be set individually for each channel via
the panel control:
Mode 00: Reception OFF.
Mode 01: Direct tone generator control.
Mode 02: Same as keyboard note on/off operation.
Mode 03: Same as auto-accompaniment chord fingering.
Mode 04: Same as the lowest-note (bass note) played in the
auto-accompaniment chord fingerings.
*2. Channel pressure handled as vibrato.
*3. For bank selection transmission only the MSB changes.
The LSB is fixed at 00H.
*4. Bank select reception.
The bank select MSB is used for melody voice and rhythm voice
switching.
The bank select LSB is ignored.
MSB 00H: GM melody voice.
MSB 7FH: GM rhythm voice.
The default for all the channels excepting channel 10 is 00H. Bank
select reception with channel 10 is not possible since channel 10
is assigned to the rhythm accompaniment. However, bank select
reception with channel 10 will be possible when you do the follow-
ing operation: turning the POWER back on while holding the C1
key down.
When the bank select MSB is 01H … 7EH, all subsequent key-ons
received will be ignored.
No voice change will occur when only a bank select is received.
When a program change is received the latest bank select value is
used.
*5. Portamento control is effective only when Reception is set in the
Multi mode.
*6. A pitch bend sensitivity message is transmitted when a panel pitch
bend range setting is made.
Pitch bend sensitivity: BnH, 64H, 00H, 65H, 00H
*7. RPN receives the following data:
Pitch bend sensitivity: BnH, 64H, 00H, 65H, 00H
Default: 02H, 00H
Fine tuning: BnH, 64H, 01H, 65H, 00H
Default: 40H, 00H
Coarse tuning: BnH, 64H, 02H, 65H, 00H
Default: 40H, 00H
Null: BnH, 64H, 7FH, 65H, 7FH
*8. Reset all controllers.
Pitch bend, channel pressure, modulation, expression, sustain,
and sostenuto are returned to their default values.
All RPN data is set to NULL.
Portamento is reset.
*9. GM melody voices 0 through 127 become panel voices 1 through
128.
Rhythm voices 0, 8, 16, 24, 25, 32, 40, and 48 become panel
voices 1 through 8.
*10. Exclusive.
<GM1 System ON> F0H, 7EH, 7FH, 09H, 01H, F7H
All parameters except MIDI Master Tuning are reset to their
default values.
<MIDI Master Volume> F0H, 7FH, 7FH, 04H, 01H, ll, mm, F7H
Allows the volume of all channels to be changed simultaneously
(universal system exclusive).
mm is used as the MIDI Master Volume value (ll is ignored).
The default value for mm is 7FH.
This message is receive-only.
<MIDI Master Tuning>
F0H, 43H, 1nH, 27H, 30H, 00H, 00H, mm, ll, cc, F7H
Allows the pitch of all channels to be changed simultaneously
(panel tuning).
mmll is used as the MIDI Master Tuning value, an the actual
tuning is shown by the expression:
T=Mx200/256-100
Where T is the actual tuning value in cents. M is decimal value
represented by 1-byte using bits 0…3 of mm as the MSB and
bits 0…3 of ll as the LSB.
The default values of mm and ll are 07H and 0FH, respectively.
n and cc are also recognized.
This value is not reset by a GM System ON or Reset All Con-
trollers message.
This message is transmitted and received.
<Bulk Dump>
bl and bh represent the total byte count as bl+bh*128.
CS: Checksum.
Custom accompaniment:
F0H, 43H, 76H, 11H, bl, bh, <Data>, cs, F7H
Multi pad:
F0H, 43H, 76H, 12H, bl, bh, <Data>, cs, F7H
Song memory:
F0H, 43H, 76H, 13H, bl, bh, <Data>, cs, F7H
Registration memory: F0H, 43H, 76H, 14H, bl, bh, <Data>, cs, F7H
<Panel Control>
Dual data change:
F0H, 43H, 76H, 17H, 04H, <Data>, F7H
Dual ON/OFF:
F0H, 43H, 76H, 17H, 05H, <Data>, F7H
Harmony/Effect:
F0H, 43H, 76H, 17H, 0EH, <Data>, F7H
DSP type:
F0H, 43H, 76H, 17H, 0EH, 00H, 01H, <Data>, F7H
Chord/Bass:
F0H, 43H, 76H, 17H, 0BH, <Data>, F7H
*11. Internal/external clock selectable.
*12. Operation when a start/stop command is received is determined by
the RECEIVE CHANNEL, CLOCK, AND COMMAND panel set-
tings.
0. Start/stop command ignored.
1. Auto-accompaniment start/stop.
2. Song memory start/stop.
Continue neither transmitted nor received.
d’implémentation / Gráfico de implememtación
