Moxa Command Line Interface (FW_5.x) Commands
2-140
Description mst Configure mstp
max-age Set mstp max age
age mstp max age
Defaults age=20
Command
Modes
Redundancy configuration
Usage
Guidelines
2*( hello-time + 1.0 sec) <= max-age <= 2*( forward-delay - 1.0 sec)
age is range from 6 to 40
Examples
MOXA# configure terminal
MOXA(config)# redundancy
MOXA(config-rdnt)# spanning-tree mst max-age 10
<UINT:age> - Set mstp max age
Error
messages
MSTP max age must be in the range from 6 to 40
MSTP max age set error
Related
commands
show redundancy mst configuration
spanning-tree mst max-hops
Use the spanning-tree max-hops redundancy configuration command on the switch to set the switch
maximum hop number for Multiple Spanning Tree (MSTP). Use the no form of this command to return to the
default setting.
Commands
spanning-tree mst max-hops hops
no spanning-tree mst max-hops
Syntax
Description
spanning-tree Configure spanning tree
mst
Configure mstp
max-hops Set mstp max hops
hops mstp max hops
Defaults hops=20
Command
Modes
Redundancy configuration
Usage
Guidelines
2*( hello-time + 1.0 sec) <= max-age <= 2*( forward-delay - 1.0 sec)
hops is range from 6 to 40
Examples
MOXA# configure terminal
MOXA(config)# redundancy
MOXA(config-rdnt)# spanning-tree mst max-hops 10
Error
messages
MSTP max hops must be in the range from 6 to 40
MSTP max hops set error
Related
commands
show redundancy mst configuration
spanning-tree mst name
Use the spanning-tree mst name redundancy configuration command on the switch stack to set the name of
MSTP region for the spanning-tree.
Commands
spanning-tree mst name region-name
Syntax
Description
spanning-tree Configure spanning tree
mst Configure mstp
