Moxa Command Line Interface (FW_5.x) Commands
2-61
Defaults Time-tabling is default disabled.
start_time is default 0
end_time is default 24
Command
Modes
Interface configuration
Usage
Guidelines
poe can only be enabled on poe-supported-interface
week_day is range from 0 to 6, 0 means Monday
end_time cannot be smaller than start_time
Examples
MOXA# configure terminal
MOXA(config)# interface ethernet 1/1
MOXA(config-if)# poe enable
MOXA(config-if)# poe timetabling
MOXA(config-if)# poe timetabling 0
MOXA(config-if)# poe timetabling 0 12
MOXA(config-if)# poe timetabling 0 12 24
MOXA(config-if)# no poe timetabling 0
MOXA(config-if)# no poe timetabling
Error
messages
This port is not a POE port.
End time should be greater than Start time.
Related
commands
poe enable
port-security
Use the port-security command on the switch to configure the port security function. Use the no form of this
command to disable the port security function on the switch.
Commands
[no] port security [MacAddress [vid vid]]
Syntax
Description
port-security Set port security
MAC-address MAC address XX:XX:XX:XX:XX:XX
vid Add mac address with vid
Defaults N/A
Command
Modes
interface configuration
Usage
Guidelines
N/A
Examples
MOXA# config
MOXA(config)# interface Ethernet 1/1
MOXA(config-if)# switchport port-security
MOXA(port-sec)# port-security 00:00:00:00:00:01
MOXA(port-sec)# port-security 00:00:00:00:00:01 vid 2
MOXA(config-if)# no port-security 00:00:00:00:00:01
Error messages Add new static unicast MAC address Fail !!!
Related
commands
N/A
profinetio
Use the profinetio command to disable/enable PROFINET support.
Commands
profientio
