Moxa Command Line Interface (FW_5.x) Commands
2-162
warning-notification system-event
Use warning-notification system-event global configuration commands to enable the system warning
events trigger to email, relay, syslog or trap. Use no form of this command to disable it.
Commands
warning-notification system-event { cold-start | warm-start | config-changed | pwr1-trans-on |
pwr2-trans-on | pwr1-trans-off | pwr2-trans-off | auth-fail | password-changed |
tacacs-auth-success |tacacs-auth-fail | radius-auth-success |radius-auth-fail | topology-changed
| coupling-changed | master-changed |master-mismatch | rstp-admin-changed |
rstp-topology-changed | turbo-ring-break | di1-trans-on|di1-trans-off| abc02-status| web-login |
rate-limited-on | rate-limited-off| port-looping | ptp-time | lldp-table-changed | fiber-warning |
login-success | account-info-changed | config-imported | cert-imported | login-failure-lockout |
mac-sticky-violation-port-disable } {action action-index | severity severity-level| active}
no warning-notification system-event { cold-start | warm-start | config-changed | pwr1-trans-on
| pwr2-trans-on | pwr1-trans-off | pwr2-trans-off | auth-fail | password-changed |
tacacs-auth-success |tacacs-auth-fail | radius-auth-success |radius-auth-fail | topology-changed
| coupling-changed | master-changed |master-mismatch | rstp-admin-changed |
rstp-topology-changed | turbo-ring-break | di1-trans-on|di1-trans-off| abc02-status| web-login |
rate-limited-on | rate-limited-off| port-looping | ptp-time | lldp-table-changed | fiber-warning |
login-success | account-info-changed | config-imported | cert-imported | login-failure-lockout |
mac-sticky-violation-port-disable } active}
Syntax
Description
warning-notification Configure warning-notification
system-event System event
cold-start Power is cut off and then reconnected.
warm-start The Moxa switch is rebooted, such as when network parameters
are changed (IP address, subnet mask, etc.).
config-changed Any configuration item has been changed.
pwr1-trans-on The Moxa switch power 1 is powered on.
pwr2-trans-on The Moxa switch power 2 is powered on.
pwr1-trans-off The Moxa switch power 1 is powered down.
pwr2-trans-off The Moxa switch power 2 is powered down.
auth-fail An incorrect password was entered.
password-changed User changes the account password
tacacs-auth-success Correct authentication details were entered
tacacs-auth-fail Incorrect authentication details were entered
radius-auth-success Correct authentication details were entered
radius-auth-fail Incorrect authentication details were entered
topology-changed •
f the Master of the Turbo Ring has changed or the backup path
is activated
• If the Turbo Ring path is disconnected
• If the MSTP topology has changed
coupling-changed Backup path is activated
master-changed Master of the Turbo Ring has changed
master-mismatch Master of the Turbo Ring has mismatch
rstp-admin-changed If the RSTP root has changed
rstp-topology-change
d
If any Rapid Spanning Tree Protocol switches have changed their
position
(applies only to the root of the tree)
turbo-ring-break Turbo Ring path is disconnected
di1-trans-on Digital Input 1 is triggered by an off to on transition
di1-trans-off
Digital Input 1 is triggered by an on to off transition
abc02-status Detects if the ABC-02-USB-T is connected or disconnected to the
