Moxa TN-5516A-8PoE-WV-T [11/20] Attention

- 11 -

To remove the Moxa ToughNet Switch from the DIN rail use a screwdriver

to pull out the two spring-loaded brackets from the bottom until they are

fixed in the “locked” position. Then reverse Steps 3 and 4 above.

Wiring Requirements

WARNING

Turn the power off before disconnecting modules or wires. The

correct power supply voltage is listed on the product label. Check

the voltage of your power source to make sure you are using the

correct voltage. Do NOT use a voltage greater than what is

specified on the product label.

These devices must be supplied by a SELV source as defined in

the Low Voltage Directive 2006/95/EC and 2004/108/EC.

ATTENTION

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa switch.

This device has UL508 approval. Use copper conductors only,

75°C, and tighten to 4.5 pound-inches. For use in pollution

degree 2 environments.

ATTENTION

Safety First!

Observe all electrical codes dictating the maximum current

allowable for each wire size. If the current goes above the

maximum ratings, the wiring could overheat, causing serious

damage to your equipment.
