Overview

The Moxa Industrial Media Converter IMC-21 series consists of entry-level

10/100BaseT(X) to 100BaseFX media converters that provide a

cost-effective solution, and are specially designed for reliable and stable

operation in harsh industrial environments.

IMC-21 accepts either a 12 to 48 VDC power input. It operates reliably in

a temperature range from -10 to 60°C, and IMC-21’s rugged hardware

design makes it ideal for demanding industrial applications, such as those

that comply with FCC, CE.

NOTE

Throughout this Hardware Installation Guide, we use IMC as an

abbreviati

on for Industrial Media Converter:

IMC = Industrial Media Converter

Package Checklist

Moxa IMC-21 is shipped with the following items. If any of these items is

missing or damaged, please contact your customer service

representative for assistance.

• IMC-21

• Quick Installation Guide (printed)

• Moxa Product Warranty booklet

Features

• Power inputs: 12 to 48 VDC

• TP port’s connection speed, Half/Full duplex mode, and Force/Auto

mode are DIP Switch selectable

• Fiber port’s Half/Full duplex mode is DIP Switch selectable

• Supports Link Fault Pass-Through (LFP)

• DIN-Rail mountable

• Multi-mode and single mode models with SC or ST fiber connectors

are available

• Operating temperature range from -10 to 60°C
