- 12 -
working properly.
TP Port LED Indicators (Port Interface)
100M Green
On
TP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps
Off
TP port’s 100 Mbps link is inactive.
10M Amber
On
TP port’s 10 Mbps link is active.
Blink
Data is being transmitted at 10 Mbps
Off
TP port’s 10 Mbps link is inactive.
Specifications
WLAN Interface
Standards
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3af for Power-over-Ethernet*
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
*Support for PoE discontinued starting with HW
Rev 2.0.0
Spread Spectrum and
Modulation (typical)
DSSS with DBPSK, DQPSK, CCK
OFDM with BPSK, QPSK, 16QAM, 64QAM
802.11b:
• CCK @ 11/5.5 Mbps
• DQPSK @ 2 Mbps
• DBPSK @ 11 Mbps
802.11a/g:
• 64QAM @ 54/48 Mbps
• 16QAM @ 36/24 Mbps
• QPSK @ 18/12 Mbps
• BPSK @ 9/6 Mbps
Operating Channels
(central frequency)
US:
• 2.412 to 2.462 GHz (11 channels)
• 5.18 to 5.24 GHz (4 channels)
EU:
• 2.412 to 2.472 GHz (13 channels)
• 5.18 to 5.24 GHz (4 channels)
JP:
• 2.412 to 2.472 GHz (13 channels, OFDM)
• 2.412 to 2.484 GHz (14 channels, DSSS)
• 5.18 to 5.24 GHz (4 channels for W52)
Security
• SSID broadcast enable/disable
• Firewall for MAC/IP/Protocol/Port-based
filtering
• 64-bit and 128-bit WEP encryption,
WPA/WPA2-Personal and Enterprise (IEEE
802.1X/RADIUS, TKIP and AES)
Transmission Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
TX Transmit Power 802.11b:
• Typ. 23±1.5 dBm @ 1 to 11 Mbps
802.11g:
• Typ. 20±1.5 dBm @ 6 to 24 Mbps
• Typ. 19±1.5 dBm @ 36 Mbps
